F408 V4 Flight Controller

F408 V4 Flight Controller

$59.99 USD
$59.99 USD
Sale Sold out
MCU STM32F405
Gyro ICM42688-P
Barometer SPL06
OSD AT7456E
Black Box 16M onboard
Bluetooth Tuning Not Supported
Dual Camera Switching Supported
DJI Sky Port Insertion Not Supported
USB Port Type-C
Input Voltage 3S–8S LiPo battery
BEC Output 5V max output 3A, 10V max output 2A
UART 5 sets
• UART1: VTX data settings
• UART2: Receiver
• UART3: Customized
• UART4: GPS
• UART5: ESC telemetry
ESC Signal Outputs 8
I2C Included (SDA & SCL pads for compass)
LED Pads Included (WS2812 LED control)
Buzzer Pads Included
BOOT Button Included
Firmware Betaflight
Mounting 30.5 x 30.5 mm
Dimensions 37 × 37 mm
Weight 7g
